Voxa Harmonia – az eredeti faerezetes címlapkép

Instruments, technology and preservation

Instrument building and preservation

The name joins two ideas: Vox, meaning voice, and Doxa, meaning glory. Instrument building, restoration and modern technology in one workshop.

Workshop and development

Classical instruments, carefully considered technology

Instrument building and restoration

Building, tuning, repair and modernisation of organs, pianos, harmoniums and electronic instruments.

ModSystem

A modular, expandable and repairable system for digital, virtual and MIDI instruments.

Custom design

Coordinated design and implementation of mechanics, electronics, amplification, consoles and cases.

mezzoPIANO

The independent mezzoPIANO site presents the story and models of the hybrid pianos.

Visit mezzoPIANO

ModSystem

Current product catalogue

MODSYSTEM / HYBRID ORGAN

New: hybrid-organ driver modules

From the console to real pipe magnets: the Driver controller, isolated Gateway and local power boards have distinct roles. The six new modules are in development; complete system firmware and physical validation remain to be finalised.

Ctrl Module Driver → Organ Bus Gateway → isolated RS-485 branch → Magnet / Stop / Slider / Motor nodes. Each power bank needs a local, separately fused DC supply.

Hall Velocity 1/8/12 → 88 Velocity Base (Pico 2) → USB-MIDI → computer. Separate 5 V/2 A adapter; star-wired 3.3 V Hall-board supplies, separate from signal headers.

Every PCB-mounted component, including separately procured ICs, MOSFETs, Pico modules, capacitors and connectors, with assembly. External magnets, motors, supplies, braking resistors, cooling, mechanics and installation are separate peripherals. Development-module prices are planned and availability must be confirmed.

ModSystem →
Ctrl Module

Central control

Ctrl Module

The updated central ModSystem controller brings together five manuals, a pedalboard and the stop/LED/expression module, communicating with the computer through the Pico USB connection.

Details
88 Velocity Base

88-key velocity system

88 Velocity Base

Standalone Pico 2 USB-MIDI piano controller for up to 88 analogue Hall signals. Hall Velocity 1/8/12 boards connect directly; no separate Ctrl Module is required.

Details
Hall Velocity 1

88-key velocity system

Hall Velocity 1

A board with 1 analogue Hall sensor for magnetic key-motion sensing. Outputs connect to the analogue inputs of 88 Velocity Base.

Details
Hall Velocity 8

88-key velocity system

Hall Velocity 8

A board with 8 analogue Hall sensors for magnetic key-motion sensing. Outputs connect to the analogue inputs of 88 Velocity Base.

Details
Hall Velocity 12

88-key velocity system

Hall Velocity 12

A board with 12 analogue Hall sensors for magnetic key-motion sensing. Outputs connect to the analogue inputs of 88 Velocity Base.

Details
Control Module Driver

Central control

Control Module Driver

The central ModSystem controller built around a Raspberry Pi Pico. It connects manuals, a pedalboard and the stop module, with separate driver-bus connections.

Details
Control Module LED

LED control

Control Module LED

A dedicated USB-MIDI controller for daisy-chained LED Driver 64 boards. It converts computer MIDI messages into LED-driver control signals.

Details
LED Driver 64

LED driving

LED Driver 64

A driver board for 64 individual LED channels, using four TLC5925 constant-current ICs. BUS_IN and CHAIN_OUT allow daisy-chaining to further boards.

Details
Manual 64 Hall

Keyboard – digital Hall

Manual 64 Hall

A manual board for 64 individual digital Hall sensors. Magnetic key sensing provides contactless on/off states to the central controller.

Details
Manual 64 Reed

Keyboard – switch matrix

Manual 64 Reed

A manual board that reads an 8×8 switch matrix for reed-switch or other suitable contact keyboards. The matrix accepts 64 switching points.

Details
Manual 64 Velocity

Keyboard – analogue Hall

Manual 64 Velocity

A board sampling 64 analogue Hall inputs to track key movement. Central-controller firmware can derive key velocity from the 12-bit ADC’s raw samples.

Details
Stop Expression 128

Stops and expression

Stop Expression 128

A module for stop switches and four analogue expression controls. It forwards switch-matrix and pedal signals to the central controller.

Details
Stop LED Expression 192

Stops, LEDs and expression

Stop LED Expression 192

A board combining three 8×8 stop banks, LED feedback and four expression inputs. A single module handles switch scanning and illuminated stop indication.

Details
8×8 Scan Matrix LED

LED-matrix connections

8×8 Scan Matrix LED

An 8×8 row–column connection board for an LED matrix. IDC connectors provide organised wiring for 64 matrix positions.

Details
8×8 Scan Matrix – diode

Switch matrix

8×8 Scan Matrix – diode

A Col-to-Row matrix board organising 64 switching points. Individual 1N4148W diodes provide isolation within the switch network.

Details
Organ Bus Gateway

Hybrid organ · power control

Organ Bus Gateway

In development · planned board

Gateway between the ModSystem Driver controller and four galvanically isolated RS-485 field-bus branches. One gateway can serve multiple daisy-chained magnet and actuator boards.

Details
Organ Magnet 64

Hybrid organ · power control

Organ Magnet 64

In development · planned board

64 independent low-side outputs for common-positive DC note magnets. Designed for smaller electro-pneumatic note magnets.

Details
Organ Magnet 32 HD

Hybrid organ · power control

Organ Magnet 32 HD

In development · planned board

32 independent low-side outputs for common-positive DC note magnets. HD version for higher-current coils.

Details
Organ Stop 16

Hybrid organ · power control

Organ Stop 16

In development · planned board

Node designed to control 16 dual-coil stop-action magnets with ON/OFF pulses. Drawknob mechanics are separate peripherals.

Details
Organ Slider 4

Hybrid organ · power control

Organ Slider 4

In development · planned board

Power node designed for pulse control of four larger dual-coil stop or slider actuators, with individual bank protection and a defined thermal envelope.

Details
Organ Motor 4

Hybrid organ · power control

Organ Motor 4

In development · planned board

Node designed for four bidirectional DC motors driving swell shutters or other organ actuators, with provisions for limit and position feedback.

Details
